Linear Vibrating Screen yog lub siab -cov khoom siv tshuaj ntsuam xyuas ua haujlwm tau tsav los ntawm ob lub vibration motors. Nws siv txoj hauv kev ntawm kev vibration trajectory, dav siv rau kev muab qhab nia thiab impurity tshem tawm cov hmoov, granular, thaiv thiab slurry cov ntaub ntawv hauv mining, metallurgy, tsev cov ntaub ntawv, thee, zaub mov, tshuaj, abrasive, yas thiab lwm yam lag luam. Nws tuaj yeem paub qhov kev tshuaj ntsuam tas mus li nrog kev ua haujlwm ruaj khov, muaj peev xwm ua haujlwm loj, siab precision thiab zoo sealing nyhuv, ua rau nws yog ib qho zoo tagnrho tshuaj ntsuam xyuas cov kab ntau lawm.
Khoom Paub meej
High - lub zog steel qauv, ruaj & ruaj khov
Kev tshuaj xyuas zoo, lub zog-txuag & txhim khu kev qha
|
Yam khoom |
Paub meej |
|
Khoom npe |
Linear Vibrating Screen |
|
Lub Hom Phiaj |
Cov khoom grading, impurity tshem tawm, hmoov tshuaj ntsuam xyuas, thaiv cov khoom sorting |
|
Functional Features |
Muaj peev xwm loj, siab precision, tsis tshua muaj suab nrov, lub neej ntev ntawm lub vijtsam, kaw tag nrho, tsis muaj plua plav to |
|
Khoom siv |
Carbon steel / 304 stainless hlau |
|
Xim |
Xiav, Grey (Customizable) |
|
Screen Mesh |
2-325 Mesh |
|
Txheej |
1-6 txheej |
|
Qhov Loj |
1000 × 2000mm, 1000 × 2500mm, 1000 × 3000mm, 1500 × 3000mm, 1500 × 4000mm |
|
Lub cev muaj zog |
0.25-3.7 kWm |
|
Installation Angle |
0-10 degree |
|
Siv tau yam mob |
Cov ntaub ntawv qhuav thiab ntub, ntau yam hmoov, granule thiab thaiv cov ntaub ntawv |
|
Keeb kwm |
Tuam Tshoj |
|
Hom |
Ruidi |
|
MOQ |
1set ib |
Khoom zoo
Kev ua haujlwm loj & Kev ua haujlwm siab:
Adopts dual- kev vibration lub cev muaj zog tsav nrog lub zog muaj zog thiab ruaj khov zoo siab, ua kom pom kev nrawm nrawm thiab kev tshuaj ntsuam xyuas, txhim kho cov zis thiab ua haujlwm zoo.
Ntev Screen Lub Neej & Hloov Yooj Yim:
Cov qauv tsim qauv tsim tshwj xeeb txhawb kev hloov pauv sai hauv 3-5 feeb. Nws yog sib xws nrog nylon, PP, tshwj xeeb steel mesh thiab lwm yam ntaub ntawv.
Zoo Sealing & Environmentally Friendly:
Cov qauv kaw tag nrho zoo tiv thaiv cov plua plav tawm, ua kom lub rooj cob qhia huv thiab ua tau raws li kev tiv thaiv ib puag ncig.
Kev siv hluav taws xob tsawg & qis suab nrov:
Lub zog vibration ruaj khov txo lub zog poob thiab khiav suab nrov, tsim kom muaj ib puag ncig ua haujlwm zoo.
Stable Structure & Strong Durability:
Lub vijtsam lub cev yog welded los ntawm dov steel phaj thiab profile nrog siab rigidity, firmness thiab ntev kev pab cuam lub neej.
Ib qho yooj yim installation & txij nkawm:
Cov qauv yooj yim, kev ua haujlwm yooj yim thiab kev saib xyuas, haum rau kev sib dhos kab nruam ua haujlwm.
Wide Application Range:
Haum rau kev tshuaj ntsuam ntau yam ntaub ntawv qhuav, dav siv nyob rau hauv ntau yam lag luam nrog muaj zog adaptability.
Txoj Cai Ua Haujlwm
Linear Vibrating Screen adopts dual vibration motors tsav. Thaum ob lub motors khiav synchronously thiab thim rov qab, lub zog zoo siab uas tsim los ntawm eccentric blocks counteracts nyob rau hauv cov kev taw qhia thaum uas tig mus rau lub cev muaj zog axis thiab superimposes mus rau hauv ib tug resultant quab yuam nyob rau hauv txoj kev ntsug. Yog li ntawd, lub zog khiav ntawm qhov screen yog ib txoj kab ncaj nraim. Raws li kev sib koom ua ke ntawm kev ua kom muaj zog thiab cov khoom siv lub ntiajteb txawj nqus, cov ntaub ntawv raug pov tseg thiab txav mus rau pem hauv ntej ntawm qhov screen, thiaj li ua tiav kev tshuaj xyuas thiab kev faib tawm.
Sau ntawv
1. Nruab lub tshuab rau ntawm lub hauv paus ruaj khov thiab ua kom nws qib kom ruaj khov.
2. Xyuas thiab fasten tag nrho cov bolts ua ntej pib, tshwj xeeb tshaj yog lub cev muaj zog kho bolts.
3. Tshem tawm cov khoom kho tsheb thauj mus los ua ntej lub hwj chim qhib.
4. Xyuas kom lub cev muaj zog kev taw qhia yog qhov tseeb.
5. Pub cov ntaub ntawv sib npaug thaum lub sijhawm ua haujlwm, tsis pub ntau dhau.
6. Tsis tu ncua xyuas qhov nro ntawm lub vijtsam thiab hnav, hloov cov khoom puas hauv lub sijhawm.
7. Khaws lub vijtsam lub cev kom deb ntawm kev sib cuag nyuaj kom tsis txhob muaj qhov txawv txav.
8. Tsis tu ncua tswj lub cev muaj zog thiab ntxiv cov roj lubricating raws li xav tau.
FAQ
Q: 1.Dab tsi cov ntaub ntawv yog linear vibrating screen haum rau?
A: Nws yog tsim rau hmoov, granular, thaiv thiab qhuav cov ntaub ntawv hauv mining, metallurgy, tsev cov ntaub ntawv, thee, zaub mov, tshuaj, abrasive thiab lwm yam lag luam.
Q: 2.Can lub npov txheej tau customized?
A: Yog, 1-6 txheej ntawm cov ntxaij vab tshaus tuaj yeem hloov kho raws li qhov yuav tsum tau ua.
Q: 3.Nws siv sijhawm ntev npaum li cas los hloov lub vijtsam?
A: Cov qauv tsim tshwj xeeb tso cai rau kev hloov pauv ceev hauv 3-5 feeb.
Q: 4.Nws puas haum rau kev siv kab sib dhos?
A: Yog, tag nrho cov qauv kaw thiab tsis siv neeg tso tawm ua rau nws zoo meej rau cov kab ntau lawm.
Q: 5.Koj puas muab kev pabcuam tom qab- muag?
A: Yog, peb muab kev cob qhia kev teeb tsa, commissioning, kev sib tham txog kev saib xyuas thiab cov khoom seem.
